The large area scan camera is the high-end series of iRAYPLE area scan cameras that offer resolutions ranging from 5 MP to 604 MP and are designed to provide high resolution, high frame rate, and high image quality. An excellent ISP algorithm is utilized to ensure optimal image effects. Some models also have TEC cooling capabilities, which help maintain a stable temperature for the sensor. This makes them well-suited for industries such as EV, photovoltaic, semiconductor, liquid crystal, and more.
AX5A22MP050E
Categories: Large Area Scan Series
Description
Product Details
● CXP-12 interface, 4 x 12.5Gbps theoretical transfer bandwidth;
● Support hardware trigger/free run mode;
● Support pixel-by-pixel FFC function;
● Support multiple image data formats output, ROI and etc.；
● Support PoCXP and DC 24V power supply;
● Conforms to CoaXPress protocol and GenICam standard;
● Conform to CE, KC and RoHS;
